OEM Solar Panel Manufacture Solar Panels
- Model NO.:
- 260W太阳能板
- Delivery:
- FOB
OEM Solar Panel 365 watt Manufacture Solar Panels
First-class solar panel warranty Reliable quality
13 years material & technology guarantee
High-transmissivity low-iron tempered glass, strong aluminium frame using UV-resistant silicon；
Aesthetic appearance with excellent efficiency based on innovative photovoltalic technologies；
High quality,strong aluminium frame
Solar Cell
* High output-power: conversation efficiency is about 18%-21%
* High shunt-resistance: adapt the several environmental conditions.
* Low CTM(cell to module)loss: Operating Temperature:-40°C to +80°C
* Bypass diode minimizes the power drop by shade
Glass
* High-transmittance and low reflection
* Inspection:GB15763.2-2005.ISO9050
* High solar transmittance
* High mechanical strength
Frame
* Aluminium extrusion profile with prompt delivery
* Available in customized surface finish
* Excellent material for smooth and subtle edges
* Elegant appearance
Junction Box
* High current and voltage carrying capacity
* Simple, quick and safe effective field assembly
* IP 67 it can be used in the outdoor iron environment
* Expansion connector are available for future requirement
Maximum Power (Pmax) | 260W | 265W | 270W | 275W | 280W |
Open-circuit Voltage (Voc) | 38.1V | 38.3V | 38.4V | 38.5V | 38.7V |
Maximum Power Voltage (Vmp) | 30.6V | 30.8V | 30.9V | 31.1V | 31.4V |
Short-circuit Current (Isc) | 9.01A | 9.10A | 9.22A | 9.25A | 9.34A |
Maximum Power Current (Imp) | 8.05A | 9.61A | 8.73A | 8.84A | 8.92A |
Module Efficiency(%) | 18.9% | 16.21% | 16.51% | 16.82% | 17.12% |
Power Tolerance | 0~+5W | ||||
Standard Test Environment | Irradiance 1000W/m2, Cell Temperature 25℃,Spectrum AM 1.5 | ||||
