Model NO.:
DQ1600
Delivery:
FOB

1000w dc to ac 12v 24v solar pure sine wave inverter with battery charger

Pure Sine Wave Inverter

 pure sine wave inverter

grid hybrid solar power inverter

 Product Description

Model

DQ1600A

1K-01

DQ1600A

1K5-01

DQ1600A

2K-01

DQ1600B

3K-01

DQ1600B

4K-01

DQ1600B

5K-01

DQ1600B

6K-01

Rated power

1000W

1500W

2000W

3000W

4000W

5000W

6000W

Battery rate voltage

12V/24V/48VDC

24V/48VDC

48V/96VDC

Battery charge current

30A(default)-C0-C6

Equalization charge

14V/28V/56V/112V

Battery type

U0-U7

Input voltage

85-138VAC/170-275V

Input frequency

45-65HZ

Output voltage

110V/220VAC+-5%(inversion mode)

Frequency

50/60HZ+-1%(inversion mode)

Output waveform

Pure sine wave

Transfer time

<10ms(typical load)

Over load

110-120% 30S;>160% 300ms

Ambient temperature for storage

 -15-+50℃

Operation/storage conditions

0-90%(no condensation)

External dimensions

480*222*182mm

655*248*182mm

Packing dimension

560*290*235mm

735*316*235mm

Feature

1. Combine pure sine wave inverter and battery charger in one machine

2. Smart 4 steps charging, multi types of batteries to choose from

3. Wide input voltage range

4. Full protection from low battery voltage, over loading and short circuit

5. Use reliable MCU controlling unit

6. Remote control function

7. Easy to install and operate;

8. Labor free. When grid power supply is abnormal. the system will start battery power supply mode,

9. When the grid power recover, the UPS will start automatically and provide power to loading.

10. Auto switch between grid and batteries.
